Engine Type: Single-Cylinder Displacement: 27 cu. in. (443 cc) Bore x Stroke: Bore: 3.5 in. (89 mm); Stroke: 2.8 in. (71.2 mm) Cylinders: 1 Engine Cooling: Liquid Fuel System: Gas Starting System: Electric Front Suspension: Double A-Arm Front Travel: 7.6 in. (193 mm) Front Brake Type: Dual Hydraulic Disc Front Tires: Maxxis® AT 24 x 8 - 12 Rear Travel: 7.9 in. (200.7 mm) Rear Suspension: Independent Double A-Arm Rear Brake Type: Hydraulic Disc Rear Tires: Maxxis® AT 24 x 10 - 12 Frame: Steel Dry Weight: 648.3 lb. (294 kg.) Towing Capacity: 1050 lb. (476.3 kg.) Fuel Capacity: 4.2 gal. (15.9 L) Ground Clearance: 9.3 in. (235 mm) Machine Dimensions (LxWxH): L: 80.1 in. (2035 mm); W: 43.3 in. (1110 mm); H: 46.7 in. (1185 mm) Wheelbase: 47.8 in. (1215 mm) Drive Train: Continuously Variable (CVT) Speedometer: Standard Odometer: Standard
