Engine Type: OHV longitudinally mounted single-cylinder four-stroke engine Displacement: 475cc Bore x Stroke: 92.0 mm x 71.5 mm Cylinders: 1 Engine Cooling: Liquid Fuel System: PGM-FI Starting System: Electric with optional auxiliary recoil Front Suspension: Independent double-wishbone Front Travel: 7.28 in. Front Brake Type: 190 mm hydraulic discs Front Tires: 25 x 8-12 Rear Suspension: Independent dual-arm Rear Travel: 8.46 in. Rear Brake Type: 170 mm hydraulic disc Rear Tires: 25 x 10-12 Dry Weight: Curb Weight: 719 lb. Towing Capacity: 1322 lb. Fuel Capacity: 3.9 gal., including 1.3-gal. reserve Ground Clearance: 9.4 in. Machine Dimensions (LxWxH): 84.5 in. x 47.4 in. x 48.6 in. Wheelbase: 50.9 in. Drive Train: Direct front and rear driveshafts with TraxLok® and locking front differential Transmission: Five-speed automatic dual-clutch transmission with reverse Colors: Red, Olive
