Engine Type: Single-Cylinder Displacement: 41.8 cu. in. (686 cc) Bore x Stroke: Bore: 4.02 in. (102 mm); Stroke: 3.31 in. (84 mm) Cylinders: 1 Engine Cooling: Liquid Fuel System: Gas Starting System: Electric Front Suspension: Independent Double Wishbone Front Travel: 7.1 in. (180.3 mm) Front Brake Type: Dual Hydraulic Disc Front Tires: Maxxis® AT25 x 8 - 12 MU19 Rear Suspension: Independent Double Wishbone Rear Travel: 9.1 in. (231.1 mm) Rear Brake Type: Sealed Oil Bath Multi-Disc Rear Tires: Maxxis® AT25 x 10 - 12 MU20 Frame: Steel Towing Capacity: 1300 lb. (589.7 kg.) Fuel Capacity: 4.8 gal. (18.2 L) Ground Clearance: 10.8 in. (274.3 mm) Machine Dimensions (LxWxH): L: 81.5 in. (2070.1 mm); W: 46.5 in. (1181.1 mm); H: 48.8 in. (1239.5 mm) Wheelbase: 49.2 in. (1249.7 mm) Drive Train: Continuously Variable (CVT)
