Engine Type: 675cc liquid-cooled OHV single-cylinder four-stroke Displacement: 675cc Bore and Stroke: 102mm x 82.6mm Cooling: Liquid-Cooled Compression Ratio: 9.2:1 Fuel System: Electronic fuel injection (PGM-FI) Ignition: Full-transistorized type with electronic advance Front Suspension: Independent double-wishbone; 5.9-inch travel Front Brakes: 200mm hydraulic disc with 51.1mm caliper Front Tire: Maxxis Big Horn 25 x 10-12 bias Rear Suspension: Independent double-wishbone; 7.1-inch travel with adjustable preload Rear Brakes: 200mm hydraulic disc with 30.3mm caliper Rear Tire: Maxxis Big Horn 25 x 10-12 bias Dry Weight: 1,433 lb. (curb weight) Wheelbase: 75.7 in. Front Travel: 5.9 in. Rear Travel: 7.1 in. Ground Clearance: 10.3 in. Fuel Capacity: 7.9 gal., including 1.5-gal. reserve Towing Capacity: 1,500 lb. Transmission: Automotive-style with hydraulic torque converter; three forward gears and Reverse; three drive modes 2WD, 4WD, and 4WD with all-wheel differential lock Drive System: Direct front and rear driveshafts Colors: Red, Olive
